Api 5l X 60 Psl 1
API 5L X60 PSL 1 line pipe supplied from domestic and international mills with broad OD, wall, schedule, coating, and end-finish options. Includes multiple weld/manufacturing alternatives, custom lengths up to 300 ft, optional internal coating services, and X60 physical/mechanical property data and chemistry excerpts as provided.
Overview (As Provided)
- Inventory referenced for API 5L X60 PSL 1 pipe and carbon steel pipe.
- Supply range referenced: 2"–42" carbon steel pipe from domestic and international mills.
- Large OD used steel pipe referenced as a specialty.
Pipe Dimensions / Supply Table (As Provided)
| Trade Name | API 5L X 60 PSL 1 Pipe |
|---|---|
| Other Grades (As Listed) |
api5lx65, api 5l x65, API 5L GR.B PSL 1, API 5L X 42 PSL 1, API 5L X 46 PSL 1, API 5L X 52 PSL 1, API 5L X 56 PSL 1, API 5L X 60 PSL 1, API 5L X 65 PSL 1, API 5L X 70 PSL 1, API 5L GR.B PSL 2, API 5L X42 PSL 2, API 5L X46 PSL 2, API 5L X52 PSL 2, API 5L X56 PSL 2, API 5L X60 PSL 2, API 5L X65 PSL 2, API 5L X70 PSL 2.
|
| Weld / Manufacturing Alternatives | ERW, HF, DSAW/SAWL, SMLS, HSAW |
| OD Size Range |
|
| Wall Ranges |
|
| Lengths | Single Random, Double Random, Custom (up to 300') |
| Grades (As Listed) | ASTM A53, ASTM A106, ASTM A179, ASTM A192, ST35.8, ST37, ST42, ST52, E235, E355, S235JRH, S275JR, S355JOH, P235TR1, 10#, 20#, 45#, Q235, Q345 |
| Schedules | SCH5, SCH10, SCH20, SCH30, SCH40, SCH80, SCH120, SCH140, SCH160, SCHXS, SCHXXS |
| Surface Finishes | Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap |
| End Finishes | Beveled, Square Cut, Threaded & Coupled |
| Additional Services | Internal Coating |
API 5L PSL 1 Physical / Mechanical Properties (As Provided)
| API 5L Grade | Yield Strength (min, ksi) | Tensile Strength (min, ksi) | Yield to Tensile Ratio (max) | Elongation (min, %) |
|---|---|---|---|---|
| A | 30 | 48 | 0.93 | 28 |
| B | 35 | 60 | 0.93 | 23 |
| X60 | 60 | 75 | 0.93 | 19 |
API 5L X60 (PSL1) Strength Values (As Provided)
- Minimum Yield Strength: 60,200 psi
- Maximum Yield Strength: None
- Minimum Tensile Strength: 75,400 psi
- Maximum Tensile Strength: None
- Notes: Standard line pipe grade specified in API specification 5L (as stated).
Grade B Strength Reference (As Provided)
Notes: This grade may be used for standard pipe, line pipe or conduit pipe as specified in the various ASTM and API specifications (as stated).
| Property | Grade B (ASTM A53, A106, A523) | API 5LR | API 5L PSL2 |
|---|---|---|---|
| Minimum Yield Strength | 35,000 psi | 35,500 | 35,000 psi |
| Maximum Yield Strength | None | 65,000 psi | |
| Minimum Tensile Strength | 60,000 psi | 60,200 | 60,000 psi |
| Maximum Tensile Strength | None | 110,000 psi |
API 5L X60 Industry Specification (Chemistry Excerpt) (As Provided)
| Referenced Standards | C | Si | Mn | P | S | V | Nb | Ti |
|---|---|---|---|---|---|---|---|---|
| ASTM A105, A106, A234, A333, A350, A420, A694, A860 | 0.16 | 0.45 | 1.65 | 0.020 | 0.010 | 0.08 | 0.05 | 0.04 |
Note: The source text includes table-like content pasted as plain text; values have been structured into HTML tables while preserving the provided wording and units.
